The cardiac hospital: what it costs, and what sets the number

The project this is drawn from

The numbers here come from a hospital we are extending, not a textbook.

Studio Athenos is designing the expansion of Dr. C.M. Chopra Hospital & Heart Care Centre in Chomu, a heart-care hospital led by a cardiologist, from its original size to 150 beds. Chomu is a tier-3 town in the Jaipur district — a real catchment, a real budget, and a building that has to carry serious cardiac work without metro economics. Everything below is the cost logic of that project, set out plainly.

What the building actually costs

An architect can state this plainly: a rate per square foot, and a number per bed.

A cardiac hospital’s building cost falls into two parts the architect controls. The civil and structure — foundation, frame, masonry, flooring, finishes and facade — runs around ₹2,000–2,300 per sq ft in a tier-3 location like Chomu. The services — electrical, HVAC, plumbing, medical gas and fire-fighting — add roughly ₹1,000–1,200 per sq ft, weighted toward the theatres, critical care and cath lab where the air-change and power demands concentrate.

Together, that is about ₹3,200 per sq ft for the building, within a working band of ₹2,900–3,600. At a disciplined 600 sq ft per bed, the 150-bed facility comes to roughly ₹29 crore to build — structure and services, and nothing outside an architect’s scope. That is the honest starting number. Everything below either raises it or lowers it.

Civil & structure

Services

Civil & structure ~₹2,000–2,300 · services ~₹1,000–1,200 per sq ft. The services share concentrates in the theatres, critical care and cath lab.

What sets the number

The same hospital can be built at ₹17 lakh a bed or twice that. A few decisions decide which.

The first is location. Tier-3 rates sit well below the metros: the same building drawn for a tier-1 city is built at ₹4,000–7,000 per sq ft, a difference made of labour, material logistics and local compliance — not of a better hospital. Building in Chomu is a cost advantage, not a compromise.

The widest swing is grade of finish. A durable, clinical-grade finish and a premium, hotel-like one can differ by more than the entire structure beneath them. Finish is visible, so it is where a budget most often leaks money that the building’s performance never returns.

Next is the share of high-acuity floor. Operating theatres, the cath lab and critical care are each built at two to three times the rate of a ward. A hospital that is forty per cent high-acuity costs far more per square foot than one that is twenty, at the very same finish grade. This, not the word “cardiac”, is the real premium.

The cardiac premium, precisely

The higher cost is explained by the rooms, not by the speciality.

A cath lab’s room — its shielding, dedicated power and isolation, cooling and structural provision — is built at ₹40 lakh to ₹1 crore before the imaging machine ever arrives. That is one room. Add the operating theatres, the power and gas redundancy a critical-care unit demands, and the high air-change ventilation those zones require, and the cardiac hospital’s higher figure is fully accounted for — by the density of high-specification space it carries, not by cardiology as a label.

This, not the word “cardiac”, is the real premium — the density of high-specification space the building carries.

The single-specialist factor

When the hospital is built around one cardiologist, the money follows his time.

A heart-care hospital organised around a single cardiologist is costed differently from a multi-speciality one, and the reason is operational, not structural. At Chomu, the cardiologist is needed in both the outpatient department and the cath lab — so the scarcest asset in the building is his time, not its floor area. The spend goes to making the link between those two rooms short and direct. In a multi-speciality hospital no single person is that critical, and the money spreads across balanced adjacencies instead.

Where design actually touches the cost

It barely moves what the building costs to build. It decides what it costs to live with.

The rates above hold whether the plan is sharp or clumsy — design is not where capital cost is won or lost. Design decides cost after the building opens. A poor plan does not cost more to construct; it costs more to run, every day, for twenty years, and far more to change when the hospital outgrows it. That is the only honest claim an architect should make about cost: the building is priced by the market, but the plan decides what that building costs you to keep. It is also why an extension, planned well, protects the money already in the ground.

The real cost question

The building cost is knowable, and it should be stated plainly. What separates a sound budget from a failed one is not the rate — it is the match between the grade built, the acuity carried, and the catchment served. Build above the catchment and the money never returns. Build below the acuity and the hospital cannot do its work. The number is set the moment those three are decided.
